Audio system feature, speaker system (Includes 6 speakers.)

Tire Pressure Monitor System (does not apply to spare tire)

Air bags, seat-mounted side-impact, driver and right-front passenger for thorax and pelvic protection (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat outboard occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your child\'s age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. See the Owner\'s Manual and child safety seat instructions for more safety information.)

Air bags, head curtain side-impact, front outboard seating positions with rollover sensor (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat outboard occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your child\'s age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. See the Owner\'s Manual and child safety seat instructions for more safety information.)

Air bags, frontal, driver and right-front passenger with Passenger Sensing System (Always use safety belts and the correct child restraints for your child\'s age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the Owner\'s Manual and child safety seat instructions for more safety information.)

StabiliTrak, stability control system with Proactive Roll Avoidance and traction control includes electronic trailer sway control and hill start assist

Daytime Running Lamps, with automatic exterior lamp control

Pickup box, Fleetside

Door handles, Black

Wipers, front intermittent wet-arm with pulse washers

Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass) (With Regular Cab models, includes rear window. With Extended Cab models, includes rear and rear quarter windows. With Crew Cab models or (C49) rear-window defogger, includes light-tinted rear window.)

Mirrors, outside heated power-adjustable, Black, manual-folding

Lamps, dual cargo area lamps

Headlamps, dual halogen composite with automatic exterior lamp control and flash-to-pass feature

Grille, chrome surround

Moldings, bodyside, body-colored (Moldings are deleted if any SEO paint is ordered.)

Air dam, Black

Bumper, rear chrome, step-style with pad

Bumper, front chrome (Includes chrome bumper bar and end caps with painted silver lower section.)

Tire carrier, outside spare, winch-type mounted under frame at rear

Spare tire lock keyed cylinder lock that utilizes same key as ignition and door

Wheel, 17\" (43.2 cm) steel spare (spare wheel will not cosmetically match the other 4 wheels)

Tires, P245/70R17 all-season, blackwall includes a blackwall spare tire (Requires 2WD models.)

Wheels, 4 - 17\" x 7.5\" (43.2 cm x 19.1 cm) 6-lug chrome-styled steel includes chrome center caps (spare wheel will not cosmetically match the other 4 wheels)

Mirror, inside rearview manual day/night

Power outlets, 2 auxiliary instrument panel-mounted with covers, 12-volt

Cup holders, front (Also includes rear cupholders on Extended and Crew Cab models.)

Cruise control, electronic with set and resume speed, located on steering wheel

Door locks, power includes Remote Keyless Entry

Windows, power, rear access door (Requires Extended Cab Models.)

Windows, power with driver Express-Down

Air conditioning, single-zone manual front climate control

Warning tones headlamp on, key-in-ignition, driver and passenger buckle up reminder and turn signal on

Driver Information Center with odometer, trip odometer and message center (monitors numerous systems depending on vehicle equipment level including low fuel, turn signal \"on\", transmission temperature and oil change notification) (Driver Information Center controls are operated through the trip odometer button unless (UK3) steering wheel mounted audio controls is ordered. On 1LT, 1SF and 1LZ, includes 8-point compass and outside temperature.)

Instrumentation, analog with speedometer, odometer, fuel level, engine temperature, and tachometer

Steering wheel, includes theft-deterrent locking feature

Steering column, Tilt-Wheel, adjustable with brake/transmission shift interlock

Seat, rear bench (folds up), full width, folding, 3-passenger (includes child seat top tether anchor) (Standard with Extended Cab models only.)

Seat adjuster, manual lumbar control on the driver-side

Lighting, interior with dome and reading lights, illuminated entry feature and backlit instrument panel switches

Coat hooks, rear driver and passenger side

Assist handle, front passenger (Also includes rear assist handles in the headliner on Extended and Crew Cab Models.)

Visors, driver and front passenger, sliding, with clip and passenger side vanity mirror with cover, Opal Gray-colored

TRANSMISSION, 4-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode (STD) (On Crew Cab models, requires (L20) Vortec 4.8L V8 SFI Flex-Fuel engine. Not available on C*10953 models.) M30:

ENGINE, VORTEC 4.8L VARIABLE VALVE TIMING V8 SFI FLEXFUEL capable of running on unleaded or up to 85% ethanol (302 hp [225.2 kW] @ 5600 rpm, 305 lb-ft torque [411.8 N-m] @ 4600 rpm), iron block (STD) L20:

PAINT, SOLID ZY1:

LS PREFERRED EQUIPMENT GROUP includes standard equipment 1LS:

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER, DRIVER AND FRONT PASSENGER MANUAL RECLINING with outboard head restraints and center fold-down armrest with storage (STD) AE7:

DARK TITANIUM, CLOTH SEAT TRIM 88B:

AUDIO SYSTEM, AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume and TheftLock (STD) US8:

REAR AXLE, 3.23 RATIO (Refer to Engine/Axle chart for availability.) GU5:

REAR AXLE, 3.73 RATIO (Refer to Engine/Axle chart for availability.) GT4:

EMISSIONS, FEDERAL REQUIREMENTS FE9:

EMISSIONS, ARIZONA, CONNECTICUT, MAINE, MARYLAND, MASSACHUSETTS, NEW JERSEY, NEW YORK, OREGON, PENNSYLVANIA, RHODE ISLAND, VERMONT AND WASHINGTON STATE REQUIREMENTS NE1:

EMISSIONS, CALIFORNIA STATE REQUIREMENTS YF5:

EMISSIONS OVERRIDE, CALIFORNIA (allows a dealer in states that require California emissions - Arizona, California, Connecticut, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island or Washington - to order Federal emissions for a vehicle that will be registered in a state that has Federal emission requirements). Do not use for vehicles that will be registered in Arizona, California, Connecticut, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island or Washington. (Requires (FE9) Federal emissions requirements. Not available in Maine or Vermont.) NB8:

EMISSIONS OVERRIDE, FEDERAL (for vehicles ordered by dealers in Federal emission states with (YF5) or (NE1) emissions - Not required for vehicles being shipped to Arizona, California, Connecticut, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island, Vermont or Washington) (Requires (YF5) California state emissions requirements or (NE1) Arizona, Connecticut, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island, Vermont or Washington state emissions requirements.) NC7:

EMISSIONS OVERRIDE, STATE-SPECIFIC (for dealers ordering vehicles in (YF5) or (NE1) emission states - Arizona, California, Connecticut, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island, Vermont and Washington) (Allows a California dealer (YF5 emissions) to order (NE1) emissions with (NB9) emissions override code for registration in (NE1) states; or, a Arizona, Connecticut, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island, Vermont and Washington dealer (NE1 emissions) to order (YF5) emissions with (NB9) emissions override code for registration in California.) NB9:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO READING TRUCK EQUIPMENT, PONTIAC MICHIGAN, AND RETURNED TO FLINT ASSEMBLY (Requires models **1**03 or **1**53. Not available on models **10543.) CJD:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO MONROE TRUCK EQUIPMENT, FLINT MICHIGAN, AND RETURNED TO FLINT ASSEMBLY (Requires models **1**03 or **1**53.) TCM:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO FT. WAYNE FLEET EQUIPMENT (Requires models **10**3. Not available on models **10543.) TRE:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO KNAPHEIDE TRUCK EQUIPMENT (Requires models **10**3. Not available on models **10543.) VDE:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO BUCKEYE TRUCK EQUIPMENT (Requires models **10703, **10903 or **10753. Not available on models **10543 or **10953.) VTT:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO W A JONES, COLUMBIA CITY, IN. Returned to Ft. Wayne Assembly for shipping to final destination. (Requires models T*10**3. Not available on models **10543.) VWB:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO LEGGETT AND PLATT/MASTERACK TRUCK EQUIPMENT (Requires models **10**3. Not available on models **10543.) VWH:

SHIP THRU, PRODUCED IN FT. WAYNE ASSEMBLY AND SHIPPED TO BRAND FX BODY COMPANY, IN AND RETURNED TO FT. WAYNE ASSEMBLY (Not available on models **10543.) A4I:

GRAYSTONE METALLIC 16U:

BLACK 41U:

IMPERIAL BLUE METALLIC (Not available with (PDA) Texas Edition, (PEB) Custom Sport Truck Package or (PEF) Florida Edition. (Note: No longer available to order for C*1**03 and C*1**53 models)) *No Longer Factory Orderable, See Dealer for Current Availability* 37U:

BLUE GRANITE METALLIC 46U:

SUMMIT WHITE 50U:

VICTORY RED 74U:

MOCHA STEEL METALLIC GHA:

SILVER ICE METALLIC GAN:

BLACK GRANITE METALLIC (Not available with (PDA) Texas Edition, (PEB) Custom Sport Truck Package or (PEF) Florida Edition. (Note: No longer available to order for C*1**03 and C*1**53 models)) *No Longer Factory Orderable, See Dealer for Current Availability* 58U:

LPO, DELUXE CHROME PACKAGE includes chrome mirror caps, door handles, recovery hooks and highly polished exhaust tip (Not available on 2WD models. Not available with (LU3) Vortec 4.3L V6 MFI engine, (VPA) Chrome Package, LPO or (DPN) outside vertical camper mirrors.) *No Longer Factory Orderable, See Dealer for Current Availability* VPD:

LPO, CHROME PACKAGE includes chrome recovery hooks and highly polished exhaust tip (Not available on 2WD models. Not available with (LU3) Vortec 4.3L V6 MFI engine, (VPD) Deluxe Chrome Package, LPO or (DPN) outside vertical camper mirrors.) *No Longer Factory Orderable, See Dealer for Current Availability* VPA:

LPO, PROTECTION PACKAGE includes rear wheelhouse liner and bed rail protector (Provides the same material as (RW1) bed rail protectors, LPO provides thus not available with (RW1).) VQG:

LPO, ON THE JOB PACKAGE includes the following dealer-installed accessories: (VZX) Skid-resistant bed liner, LPO, (RW1) Bedrail protectors, LPO and (SC0) Bed mounted tie-down hooks, LPO (Not available on C*10953 models or with the following LPO's: (VBN), (VBR) or (VQG)) PDC:

ENGINE BLOCK HEATER K05:

TRAILERING PACKAGE, HEAVY-DUTY includes trailering hitch platform and 2-inch receiver, 7- wire harness (harness includes wires for: park lamps, backup lamps, right turn, left turn, electric brake lead, battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector, wiring harness for after-market trailer brake controller (located in the instrument panel harness) and (KNP) external transmission oil cooler (Includes (Z85) Handling/Trailering Suspension Package. Also includes (G80) heavy-duty automatic locking rear differential on Retail orders only.) Z82-R:

COOLING, AUXILIARY EXTERNAL TRANSMISSION OIL COOLER, HEAVY-DUTY AIR-TO-OIL (Included and only available with (Z82) Trailering Package.) KNP:

DIFFERENTIAL, HEAVY-DUTY AUTOMATIC LOCKING REAR (Included with (Z82) Trailering Package on Retail Orders only.) G80:

TRAILER BRAKE CONTROLLER, INTEGRATED (Requires (Z82) heavy-duty trailering package. Not available with (LU3) Vortec 4.3L engine.) JL1:

LPO, ASSIST STEPS, CHROMED TUBULAR, 6" OVAL (dealer installed) (Not available with (VXJ) 3" round tubular assist steps, LPO. Not available on C*10543 models.) VXH-R:

LPO, ASSIST STEPS, CHROMED TUBULAR, 3" ROUND (dealer installed) (Not available with C*10953 models. Not available with (VXH) 6" oval tubular assist steps, LPO.) VXJ:

LPO, FRONT AND REAR MOLDED SPLASH GUARDS, BLACK with Gold bowtie logo on rear VQK:

LICENSE PLATE BRACKET, FRONT (will be forced on orders with ship-to states that require a front license plate) VK3:

LPO, CARGO MANAGEMENT SYSTEM RAILS VMK:

LPO, SLIDING BED DIVIDER (Requires (VMK) Cargo Management System Rails, LPO. Not available with (VMM) Overhead rack/bed divider, LPO.) VML:

LPO, OVERHEAD UTILITY RACK Operates and slides on the cargo management system. (Requires (VMK) Cargo Management System Rails, LPO. Not available with the following LPO's: (VQT), (VBP), (VPB).) VZV:

LPO, OVERHEAD RACK/BED DIVIDER Operates and slides on the cargo management system. Rack flips down to function as a bed divider (Requires (VMK) Cargo Management System Rails, LPO. Not available with the following LPO's: (VQT), (VBP), (VPB) or (VZV).) VMM:

LPO, STATIONARY TOOL BOX, SINGLE LID includes diamond patterned steel side storage box has codeable lock that works with ignition key (Not available with the following LPO's: (VQT), (VBP), (VBN) or (VPB). Not available on C*10953 models.) VZZ:

LPO, TONNEAU COVER, HARD TRI-FOLDING WITH VINYL COVER (Requires (RW1) Bed rail protectors, LPO. Not available on C*10953 models. Not available with (VQG) Protection Package, LPO, (VPB) Soft tonneau cover, LPO or (VBP) Hard tri-folding tonneau cover, LPO.) VQT:

LPO, TONNEAU COVER, HARD TRI-FOLDING WITH PREMIUM CLOTH COVER (Requires (RW1) Bed rail protectors, LPO. Not available on C*10953 models. Not available with (VQG) Protection Package, LPO, (VPB) Soft tonneau cover, LPO or (VQT) Hard tri-folding tonneau cover, LPO.) VBP:

LPO, TONNEAU COVER, SOFT with integrated support bows that rollup with the cover and can be stowed in behind the cab (Not available on C*10953 models. Not available with (VBP) Hard tri-folding tonneau cover, LPO or (VQT) Hard tri-folding tonneau cover, LPO.) VPB:

LPO, TONNEAU COVER, SOFT CLOTH, FOLDING (Requires (RW1) Bed rail protectors, LPO. Not available on C*10953 models. Not available with the following LPOs: (VQG), (VPB), (VBP), (VQT), (VZZ), (VZV) or (VMM).) 5JY:

LPO, RUBBER BED MAT (Not available on C*10953 models. Not available with (VBN) Bed rug, bed cover, LPO.) VBR:

LPO, BED RUG, BED COVER foam backed gray colored carpet-like material that covers the entire bed, includes logo (Not available on C*10953 models. Not available with (VBR) Rubber bed mat, LPO.) VBN:

LPO, BED LINER (Included with (PDC) On The Job Package, LPO. Not available on C*10953 models. Not available with (VBN) Bed rug, bed cover, LPO or (VBR) Rubber bed mat, LPO.) VZX:

LPO, BED RAIL PROTECTORS (Included with (PDC) On The Job Package, LPO. Not available with (VQG) Protection Package, LPO. Not available on C*10953 models.) RW1:

LPO, TIE-DOWN HOOKS, BED-MOUNTED (Included and only available with (PDC) On The Job Package, LPO.) SC0:

STEERING WHEEL CONTROLS, MOUNTED AUDIO CONTROLS (Included and only available with (UPF) Bluetooth for phone.) UK3-R:

BLUETOOTH FOR PHONE personal cell phone connectivity to vehicle audio system (Includes (UK3) steering wheel-mounted audio controls and (NP5) leather-wrapped steering wheel. Requires (UE1) OnStar and (US8) AM/FM stereo with MP3 compatible CD player. Not available with (UE0) OnStar delete or (UM7) AM/FM stereo. Requires OnStar hardware (UE1), but subscription to OnStar services not required for operation.) UPF-R:

FLOOR COVERING, BLACK RUBBERIZED-VINYL BG9:

LPO, ALL-WEATHER FLOOR MATS, EBONY DEEP RIBBED RUBBER (Extended and Crew Cab models also include rear floor mats) (Not available on C*10953 models or with (BG9) Black rubberized-vinyl floor covering.) VAV:

LPO, WHEEL THEFT-DETERRENT SYSTEM Security system that sets off the vehicle alarm system if the vehicle is jacked up or towed - designed to protect wheels and tires from theft (Requires (UPF) Bluetooth for phone.) W04-R:

STEERING WHEEL, LEATHER-WRAPPED with theft-deterrent locking feature (Included and only available with (UPF) Bluetooth for phone.) NP5:

DEFOGGER, REAR-WINDOW ELECTRIC C49:

LPO, UNDERSEAT STORAGE, COMPOSITE STORAGE BIN UNDER THE REAR SEAT VBJ:

NEW JERSEY COST SURCHARGE *Required on all vehicles ordered by New Jersey dealers* R6M:

ILLINOIS COST SURCHARGE R8Q:

NewCondition:

12C0087Stock:

2012Year:

ChevroletManufacturer:

Silverado 1500Model:

Extended Cab Standard Box 2-Wheel Drive LSTrim:

TruckBody Style:

Silver Ice MetallicExterior Color:

Dark TitaniumInterior Color:

5Mileage:

Rear Wheel DriveDrivetrain:

Vortec 4.8l Variable Valve Timing V8 Sfi Flexfuel Capable Of Running On Unleaded Or Up To 85% Ethanol (302 Hp [225.2 Kw] @ 5600 Rpm, 305 Lb-ft Torque [411.8 N-m] @ 4600 Rpm), Iron BlockEngine:

4-speed Automatic, Electronically Controlled With Od And Tow/haul Mode (on Crew Cab Models, Requires (l20) Vortec 4.8l V8 Sfi Flex-fuel Engine. Not Available On C*10953 Models.)Transmission:

4.8L/293Displacement:

302 SAE Net Horsepower @ RPM:

305 SAE Net Torque @ RPM:

14City MPG:

19Hwy MPG:

- TBD -Total Cooling System Capacity (qts):

HydroformedFrame Type:

2EPA Greenhouse Gas Score:

11.6Tons/yr of CO2 Emissions @ 15K mi/year:

600Cold Cranking Amps @ 0° F (Primary):

145Maximum Alternator Capacity (amps):

26Fuel Tank Capacity, Approx (gal):

Driver SideFuel Tank Location:

16Fuel Economy Est-Combined (N/A):

14EPA Fuel Economy Est - City (MPG):

19EPA Fuel Economy Est - Hwy (MPG):

Chevrolet Silverado 1500Vehicle Name:

Ext Cab 6.5' WidesideBody Style:

E63Body Code:

PwrSteering Type:

16.73Steering Ratio (:1), On Center:

3Steering Ratio (:1), At Lock:

46.9Turning Diameter - Curb to Curb (ft):

- TBD -Turning Diameter - Wall to Wall (ft):

3600Gross Axle Wt Rating - Front (lbs):

3750Gross Axle Wt Rating - Rear (lbs):

2882Curb Weight - Front (lbs):

2003Curb Weight - Rear (lbs):

6800Gross Vehicle Weight Rating Cap (lbs):

10000Gross Combined Wt Rating (lbs):

PwrBrake Type:

4-WheelBrake ABS System:

YesDisc - Front (Yes or ):

12.99 x 1.18Front Brake Rotor Diam x Thickness (in):

YesDrum - Rear (Yes or ):

11.61 x 2.36Rear Drum Diam x Width (in):

17 x 7.5Front Wheel Size (in):

17 x 7.5Rear Wheel Size (in):

17 x - TBD -Spare Wheel Size (in):

SteelFront Wheel Material:

SteelRear Wheel Material:

SteelSpare Wheel Material:

L20Engine Order Code:

Vortec 4.8l Variable Valve Timing V8 Sfi Flexfuel Capable Of Running On Unleaded Or Up To 85% Ethanol (302 Hp [225.2 Kw] @ 5600 Rpm, 305 Lb-ft Torque [411.8 N-m] @ 4600 Rpm), Iron BlockEngine Type:

4.8L/293Displacement:

Electronic Fuel InjectionFuel System:

302 @ 5600SAE Net Horsepower @ RPM:

305 @ 4600SAE Net Torque @ RPM:

4700Dead Weight Hitch - Max Trailer Wt. (lbs):

470Dead Weight Hitch - Max Tongue Wt. (lbs):

4700Wt Distributing Hitch - Max Trailer Wt. (lbs):

705Wt Distributing Hitch - Max Tongue Wt. (lbs):

4700Fifth Wheel Hitch - Max Trailer Wt. (lbs):

1175Fifth Wheel Hitch - Max Tongue Wt. (lbs):

6700Maximum Trailering Capacity (lbs):

78.7Cargo Box Length @ Floor (in):

61.5Cargo Box Width @ Top, Rear (in):

62.4Cargo Box Width @ Floor (in):

50.6Cargo Box Width @ Wheelhousings (in):

21.0Cargo Box (Area) Height (in):

61.5Tailgate Width (in):

60.7Cargo Volume (ft³):

- TBD -Ext'd Cab Cargo Volume (ft³):

Rear Wheel DriveDrivetrain:

M30Trans Order Code:

4Trans Type:

4-speed Automatic, Electronically Controlled With Od And Tow/haul Mode (on Crew Cab Models, Requires (l20) Vortec 4.8l V8 Sfi Flex-fuel Engine. Not Available On C*10953 Models.)Trans Description Cont.:

3.06First Gear Ratio (:1):

1.63Second Gear Ratio (:1):

1.00Third Gear Ratio (:1):

0.70Fourth Gear Ratio (:1):

2.29Reverse Ratio (:1):

6Passenger Capacity:

41.2Front Head Room (in):

41.3Front Leg Room (in):

65.2Front Shoulder Room (in):

62.5Front Hip Room (in):

39.2Second Head Room (in):

34.3Second Leg Room (in):

65.3Second Shoulder Room (in):

61.9Second Hip Room (in):

QU1Front Tire Order Code:

QU1Rear Tire Order Code:

P245/70R17Front Tire Size:

P245/70R17Rear Tire Size:

P245/70R17Spare Tire Size:

2004Front Tire Capacity (lbs):

2004Rear Tire Capacity (lbs):

- TBD -Spare Tire Capacity (lbs):

- TBD -Revolutions/Mile @ 45 mph - Front:

- TBD -Revolutions/Mile @ 45 mph - Rear:

- TBD -Revolutions/Mile @ 45 mph - Spare:

IndependentSuspension Type - Front:

2-stage multi-leafSuspension Type - Rear:

3600Spring Capacity - Front (lbs):

3750Spring Capacity - Rear (lbs):

IndependentAxle Type - Front:

Semi-FloatingAxle Type - Rear:

3600Axle Capacity - Front (lbs):

3750Axle Capacity - Rear (lbs):

3.23Axle Ratio (:1) - Rear:

1.81Shock Absorber Diameter - Front (mm):

1.38Shock Absorber Diameter - Rear (mm):

1.42Stabilizer Bar Diameter - Front (in):

143.5Wheelbase (in):

230.2Length, Overall w/o rear bumper (in):

79.9Width, Max w/o mirrors (in):

73.9Height, Overall (in):

39.4Overhang, Front (in):

47.2Overhang, Rear w/o bumper (in):

141.4Front Bumper to Back of Cab (in):

41.5Cab to Axle (in):

- TBD -Cab to End of Frame (in):

33.8Ground to Top of Load Floor (in):

- TBD -Ground to Top of Frame (in):

- TBD -Frame Width, Rear (in):

8.9Ground Clearance, Front (in):

12.1Ground Clearance, Rear (in):
